gate

SpecialNodes gate

input ports:
Name	Type	Description	Optional
condition	?0	interpreted as bool, used to select output	no

output ports:
Name	Type	Description	Optional
outputT	bool	outputs true if condition is true, and false otherwise	yes
outputF	bool	outputs false if condition is true, and true otherwise	yes

gate sends true out of its selected output, and false out of the other output. The selector is the boolean value of its sole input. If its input value is true, gate sends true from its top output (outputT) and false from its bottom output (outputF). If its input value is false, it sends false from its top output and `true from its bottom output.
